Five Battery Platforms, Engineered on One Factory Floor

EMS-ESS builds five product lines under one roof: home storage batteries, 19-inch rack modules, e-bike and scooter packs, RV and marine deep-cycle batteries, and custom smart BMS. Every line shares the same A-grade cell sourcing, the same laser-welding line and the same export compliance pack — so your second program starts faster than your first.

Engineers in white lab coats collaborating over workstations showing CAD models in the EMS-ESS engineering office

Product Lines

Five Platforms, One Factory Floor

Get Factory Quote in 24h Voltage Platform Table

5product lines

4S–32SBMS range

6,000+LFP cell cycles

10 unitsstandard MOQ

Product Lines

Six Ways We Build for OEM Buyers

Residential ESS · 16S

Home Battery Storage

Wall-mounted and stackable LiFePO4 at 51.2V 100–200Ah — 5.12–10.24 kWh per unit, 6,000+ cycles at 90–95% DoD, parallel to 16 units, IP65 enclosures.

View line →

E-Mobility · 10S–20S

E-Bike & Scooter Packs

36V, 48V, 60V and 72V packs on Samsung 50G and LG 21700 cells, in-house BMS from 20A to 80A, 10–60Ah, 50% recharge in 2.5 hours, EN 15194-ready.

View line →

Rack Storage · 16S

19" Rack Modules

51.2V 100Ah 4U blocks at 5.12 kWh each, parallel to 16 units per cabinet (81.92 kWh), UL 1973-ready design, CAN/RS485 with SNMP and LCD options.

View line →

Leisure & Marine · 4S–12S

RV & Marine Deep-Cycle

12V/24V/36V Group 24/31 drop-ins, 100A BMS with Bluetooth monitoring, 4,000–15,000 cycles, one-third the weight of the lead-acid they replace.

View line →

Electronics · 3S–32S

Custom Smart BMS

3S–32S boards at 30–500A with UART, RS485, CAN and Bluetooth 5.0, OTA firmware, passive or active balancing at 1–5A, protocol libraries on file.

View line →

Beyond Catalog

Fully Custom Packs

Custom voltage, capacity, enclosure and connector builds from 200 pcs — engineering proposal in 2 working days, sample packs in 15–20 days.

Start now →

12,000 m²dual-site factory, Shenzhen & Dongguan

280+engineers incl. BMS firmware team

1.2 GWhannual cell-to-pack capacity

15–20 dayscustom sample lead time

Shared Platforms

One Voltage-Platform Matrix Across Every Line

Each platform is a cell count, not a marketing name. 12V is 4S LiFePO4, 24V is 8S, 48V storage is 16S at 51.2V, and 72V light-electric packs are 20S Li-ion. The 36V class runs 10S Li-ion or 12S LFP (38.4V) for trolling-motor systems; 60V moped packs are quoted per project between the 48V and 72V platforms.

Parameter	12V platform · 4S	24V platform · 8S	48V platform · 16S	72V platform · 20S
Cell configuration	4S LiFePO4	8S LiFePO4	16S LiFePO4	20S Li-ion (NMC)
Nominal voltage	12.8V	25.6V	51.2V	72V
Typical capacity	50–300Ah	100–200Ah	100–200Ah	20–60Ah
Energy per pack	0.64–3.84 kWh	2.56–5.12 kWh	5.12–10.24 kWh	1.44–4.32 kWh
Voltage window	10–14.6V	20–29.2V	41–58.4V	60–84V
Discharge current (BMS)	100A	100–200A	100A cont. · 200A peak 10s	20–80A
Cycle life	4,000–15,000	4,000+	6,000+ @90–95% DoD	700–2,000+
Cell platform	prismatic LFP	prismatic LFP	EVE LF280K / CATL 314Ah	Samsung 50G / LG 21700
Product line	RV & marine deep-cycle	deep-cycle & telecom backup	home ESS & rack modules	e-bike & moped packs
Scalability	series-parallel banks	series-parallel banks	12–16 units parallel	10S / 13S / 20S strings
Certifications	UN38.3 · CE	UN38.3 · CE	UN38.3 · IEC 62619 · UL1973 opt.	UN38.3 · IEC 62133-2 · EN 15194-ready

Storage platforms run EVE LF280K (280Ah, ~6,000 cycles, ≤0.25 mΩ internal resistance) or CATL 314Ah (~180Wh/kg, 6,000–7,000+ cycles) A-grade prismatic cells — every lot delivered with capacity and internal-resistance reports. Light-electric platforms run Samsung 50G 5000mAh or LG 4800mAh 21700 cells, with LFP available where 2,000+ cycle life matters more than weight.

Custom Build Process

From Spec Sheet to Container in Four Steps

Requirement Review

Send voltage, capacity, application and target annual volume. An engineer — not a salesperson — classifies your spec against the platform matrix and replies within 24 hours.

Proposal & Samples

Specification sheet and quotation in 2 working days. Sample packs built in 15–20 days with the agreed BMS profile, cell brand and enclosure.

Production

30% deposit starts the line. 100–500 units deliver in ~15 working days; full containers in 25–30 days, with cell-lot traceability on every pack.

Export Delivery

UN-certified packaging under IMDG P903 for sea freight, state of charge set to 30% for air. UN38.3 test summary, MSDS and DG declaration travel with the shipment.

Buyer Questions

Capabilities, Answered by the Numbers

Can you build a voltage or capacity outside the platform table?

Yes. Standard-platform batteries start at 10 units so you can pilot a market. Fully custom packs — own mold, non-standard voltage, special enclosure or connector — start at 200–500 pcs depending on the line, and sample fees are credited against your first order.

Do you make the BMS in-house or buy it in?

In-house. Our BMS team covers 3S–32S boards from 30A to 500A with UART, RS485, CAN and Bluetooth 5.0, and maintains protocol libraries for Deye, Victron, Pylontech, Growatt and SMA inverters. Custom register mapping is firmware work for us, not a sourcing problem.

Which certifications come as standard?

Every line ships with UN38.3 (all 8 transport tests), CE and a 16-section MSDS. IEC 62133-2 comes through the CB scheme for consumer-adjacent packs, IEC 62619 for industrial LFP, and UL 1973 runs as a per-project program on the rack and ESS lines.

All 20+ buyer FAQs →

EMS-ESS factory floor at dusk with work lights

Send One Spec, Get a Costed Platform Proposal

Voltage, capacity, application, annual volume — an engineer maps it to a platform, a cell brand and a BMS profile, and replies within 24 hours.
