Energy storage, four ways.
One supplier, four LiFePO4-based product lines. Wall-mounted hybrid systems cover 3–12 kW for homes and small business; stackable and rack-cabinet batteries span 5.12–46.08 kWh; GTB microinverters handle module-level grid-tie conversion from 400 to 1600 W. Every line shares the same certifications and the same datasheet-first purchasing process, so you can quote, sample and order from a single point of contact.
Four catalogs, one platform.
Each line targets a different install topology. Pick by grid phase, power level and how the battery mounts — the numbers below come straight from the datasheets. Four lines, one LiFePO4 chemistry, one certification pack.
Wall-Mounted ESS
Hybrid 3–12 kW systems in white or gray, single and three-phase. 10 ms UPS-class switchover and 5-minute wall install.
Explore series
Stackable ESS
5.12 kWh modules that lock together toolless, from one module to eight. One-click autolock and 150 kg castors.
Explore series
Rack-Cabinet ESS
24 V, 48 V and 51.2 V LiFePO4 cabinets from our battery pack manufacturing partner, with 2000+ cycles at 100% DOD.
Explore series
Grid-Tie Microinverters
GTB 400–1600 W module-level inverters for 120 V and 230 V grids. 95% peak efficiency, IP65, fanless, WiFi monitoring.
Explore seriesEvery line ships with the same trust file.
Warranty, certificates and export documents are identical across the four lines, so your approval process runs once instead of four times.
- 5-year product and 10-year performance warranty on ESS lines
- CE, IEC 62109-1&-2 and UN38.3 document packs
- Grid-connection approvals for EU, UK, DE, PL, CZ, IN and PK markets
- English manuals and OEM language versions on request
Spec at a glance.
Three hardware families sit under the wall-mounted range, plus two battery lines and the GTB microinverter family. Use this table to shortlist before you open a datasheet.
| Wall-mounted power range | 3–12 kW · single & three-phase |
|---|---|
| Single-phase entry (3k/4k/5k) | 3000 / 4000 / 5000 W · 93% efficiency |
| Entry-series output current | 21.7 A (5 kW) · 17.4 A (4 kW) |
| Entry-series PV & MPPT | PV 4000 W · MPPT 64–130 V |
| Single-phase high-power (9k/10kS/11k) | 9000 / 10000 / 11400 VA · 98.2% efficiency |
| High-power PV & MPPT | PV up to 14820 W · MPPT 125–500 V |
| Three-phase (8k/10kT/12k) | 8000 / 10000 / 12000 W · 98.2% efficiency |
| Three-phase MPPT | 180–850 V · PV up to 18000 W |
| Three-phase output | 3W+N+PE 230 V / 400 V |
| Capacity range | 5.12–46.08 kWh · 1–9 battery modules |
| Switchover time | 10 ms (UPS/VDE) · 20 ms (APL) |
| Warranty | 5 years product + 10 years performance |
| ESS certifications | CE/TUV · IEC 62109 · IEC 62477 · UN38.3 |
| Microinverter range | GTB 400–1600 W · 95% peak efficiency |
| Rack-cabinet range | 24 V / 48 V / 51.2 V · 100 Ah |
Match the system to your grid.
Three starting points cover almost every residential and small commercial site.
Single-phase entry
3, 4 or 5 kW covers a standard home. 93% efficiency, PV input up to 4000 W and 1–8 batteries for 5.12–40.96 kWh.
Single-phase high-power
9, 10kS or 11k VA lifts PV to 14,820 W and efficiency to 98.2% for larger homes with heavy evening loads.
Three-phase
8, 10kT or 12k W outputs 3W+N+PE 230 V/400 V with MPPT 180–850 V for workshops and three-phase service.
Not sure which line fits?
Send your daily kWh, peak load, PV size and grid phase — our team shortlists a system within one working day.
